Send InquiryPILOT PIN
Price 3350.0 INR/ Piece
MOQ : 5 Pieces
PILOT PIN Specification
- Features
- Corrosion-resistant, Precision Ground, Durable
- Cutting Accuracy
- High Precision Fit
- Tool Type
- Guide Pin / Pilot Pin
- Operate Method
- Manual/Automatic installation in die/mold
- Drill Bits Types
- Guide Pin / Pilot Pin
- Machine Type
- Punching, Stamping, Die Equipment
- Coating Type
- Black Oxide Finish
- Usage
- INDUTRIAL
- Material
- Alloy Steel
- Shape
- PIN
- Coating
- Black Oxide
- Operation Type
- Guiding/Locating
- Length
- Approximately 80-90mm (estimated visually)
- Hardness
- High (suitable for locating and guiding)
- Diameter
- 8mm
- Product Type
- PILOT PIN
- Color
- BLACK
- Processing Type
- Machined, Ground
- Application
- Used for accurate positioning and guiding in dies and molds
- Finish
- Black Oxide, anti-corrosive surface
- Packaging Type
- Plastic Case
- Standard/Grade
- Industrial Grade
- Part Number
- 100211200
- Product Description
- Guide Pin 8mm
PILOT PIN Trade Information
- Minimum Order Quantity
- 5 Pieces
- Delivery Time
- 5 Days
About PILOT PIN
Engineered for Precision and Durability
Manufactured from premium alloy steel and finished with corrosion-resistant black oxide, the PILOT PIN ensures longevity and precise guiding or locating in die and mold operations. Its high hardness and precision ground design guarantee optimal fit and wear resistance, making it ideal for repeated industrial use.
Versatile Application in Industrial Settings
Suitable for use in punching, stamping, die, and mold equipment, this guide pin supports both manual and automated installation methods. Its role is crucial in achieving accurate alignment and positioning during tool setup, increasing the overall efficiency and lifespan of dies and molds.
FAQ's of PILOT PIN:
Q: How is the PILOT PIN with part number 100211200 used in industrial applications?
A: The PILOT PIN is typically inserted into dies and molds to provide accurate guidance and positioning of components during punching or stamping operations. Its precision ground finish and high hardness ensure reliable alignment under both manual and automated setups.Q: What benefits does the black oxide finish provide for this guide pin?
A: The black oxide finish delivers excellent corrosion resistance, protecting the guide pin from rust and surface degradation. This extends the service life of the pin, especially in demanding industrial environments where moisture and lubricants are present.Q: When should I consider replacing the PILOT PIN in my die or mold setup?
A: Replacement is advisable when you observe visible wear, deformation, or loss of precise fit within the die or mold. Regular inspections help maintain high-precision operations and prevent misalignment issues during tooling processes.Q: Where is the PILOT PIN most commonly installed?
A: This guide pin is primarily installed in dies and mold assemblies, commonly in punching or stamping machines, where it acts as a locator or guide to ensure the precise alignment of mating components.Q: What is the process for installing the PILOT PIN in equipment?
A: Installation generally involves inserting the pin into pre-machined holes within the die or mold. Depending on your setup, this can be done manually or via automated systems, ensuring the pin is seated securely for optimal guiding performance.Q: How does the PILOT PIN contribute to accurate guiding and locating in tool setups?
A: Precision machining and ground surfaces allow the PILOT PIN to engage accurately with mating holes or bushings, ensuring consistent, repeatable positioning and minimizing play during each operation cycle.
