Send InquiryWnmg080408 Turning Insert
Price 220.0 INR/ Piece
Wnmg080408 Turning Insert Specification
- Shape
- Trigon (80 )
- Grade
- P/M/K/S/N/H
- Thickness
- 4.76 Millimeter (mm)
- Usage
- INDUSRIAL
- Material
- carbide
- Product Type
- Indexable Turning Insert
- Application
- External Turning ,Internal Turning, Facing Rough Turning, Semi-Finishing Profile Turning ,CNC Turning ,General Metal Machining
- Weight
- 9 Grams (g)
- Color
- DEPENDS ON GRADE
Wnmg080408 Turning Insert Trade Information
- Minimum Order Quantity
- 30 Pieces
- Delivery Time
- 5 Days
About Wnmg080408 Turning Insert
The WNMG080408 is a premium 80 trigon (triangular) negative carbide turning insert designed for medium to rough turning applications. Its double-sided geometry provides six usable cutting edges, delivering excellent tool economy and long service life. The insert offers outstanding chip control, high edge strength, and stable machining performance, making it suitable for CNC lathes and conventional turning machines. It is widely used for machining steel, stainless steel, cast iron, and alloy steels.
Technical Specifications| Specification | Details |
|---|---|
| Product Type | Indexable Turning Insert |
| Model | WNMG080408 |
| Material | Cemented Carbide |
| Shape | Trigon (80) |
| Insert Type | Negative, Double-Sided |
| Hand | Neutral |
| Inscribed Circle (IC) | 12.7 mm |
| Cutting Edge Length (L) | 8.7 mm |
| Thickness (S) | 4.76 mm |
| Corner Radius (RE) | 0.8 mm |
| Hole Diameter (D1) | 5.16 mm |
| Included Angle | 80 |
| Number of Cutting Edges | 6 |
| Mounting Style | Screw Clamp |
| Weight (1 Piece) | Approx. 9 g |
| Color | Grade Dependent |
| Pack Size | Usually 10 Pieces |
The dimensions follow the ISO WNMG080408 standard.
Features- Premium cemented carbide substrate
- Double-sided design with six cutting edges
- High wear resistance
- Excellent edge strength
- Efficient chip control
- Stable cutting performance
- Long tool life
- High dimensional accuracy
- Suitable for continuous and interrupted cutting
- Compatible with ISO WNMG tool holders
- Suitable for dry and coolant-assisted machining
- External Turning
- Internal Turning
- Facing
- Rough Turning
- Semi-Finishing
- Profile Turning
- CNC Turning
- General Metal Machining
- Carbon Steel
- Alloy Steel
- Stainless Steel
- Cast Iron
- Tool Steel
- Hardened Steel
- Six usable cutting edges for lower tooling costs
- Excellent chip evacuation
- High wear resistance
- Stable machining performance
- Improved productivity
- Superior dimensional accuracy
- Extended insert life
- Reliable performance in industrial machining
- Good corrosion resistance during storage
- Excellent wear resistance
- Coated grades provide enhanced oxidation and corrosion resistance
- Suitable for both dry and coolant-assisted machining
- WNMG080408
- WNMG 080408
- WNMG080408 Carbide Insert
- WNMG Turning Insert
- Carbide Turning Insert
- Indexable Turning Insert
- CNC Turning Insert
- Trigon Turning Insert
- 80 Degree Turning Insert
- Negative Turning Insert
- Carbide Lathe Insert
- External Turning Insert
- Internal Turning Insert
- Facing Insert
- Rough Turning Insert
- Semi Finishing Insert
- Steel Turning Insert
- Stainless Steel Turning Insert
- Cast Iron Turning Insert
- CNC Lathe Insert
Price:
- 50
- 100
- 200
- 250
- 500
- 1000+
